Location: Home >> Products - European Market - Universal Compression Fittings

Female Flexible Elbow / WNKYFFE1612,WNKYFFE2012,WNKYFFE2034,WNKYFFE2534

Product parameters

Material:
Body material:CW602N/CW617N/Hpb58-3;
Sleeve: AISI 304;
o-ring: HNBR or EPDM, Sleeve seat: PE
Tool:
The installation tool for this serie is compatible with tools
applied in this industry of international market.The
installment is U/TH/H type.
Superiority:
1. The serrated design of the head and highly
contracted seal o-rings provides supreme connection
or the pipe and fittings.
2. The sleeve is made of stainless steel 304, designed
in accordance with mechanical pressing formability and
marked with diameter of the pipe.Observation holes
ensure proper installation of the pipe.
3. The o-ring is made of EPDM which is applicable to
water and HNBR for fuel gas. Both meet HGfT3091-2000
standard.
4. The sleeve seat is made of PE,which fixes the
sleeve and provides convenient press connection while the
pipe inserts the sleeve.


Back
